Description
Quality Aftermarket Front Wheel 6 Lug
Fits Cockshutt Tractor Models:
E2 (CO-OP), 20
It is recommended to measure BEFORE purchase. A different size may have been installed on your tractor at one time. Please contact us if you’d like further verification before you purchase.
JJAgParts is not responsible for return shipping on misordered rims.
Specifications
- Use with 4.00 x 15″ – 5.50 x 15″ tires
- 3″ wide (bead to bead) x 15″ diameter (bead to bead)
- 6 lug bolt hole
- 4.625″ inside diameter pilot
- 3″ center to center lug bolts
- 3.25″ backspacing
- 4.750″ center hole diameter
- Yellow powder coat paint
To determine backspacing, lay the wheel flat on the ground with the back of the wheel facing up. Next, lay a straightedge across the wheel and measure the distance from the backside of the mounting surface to the straightedge.
To determine width of rim, measure on the inside (bead to bead), NOT outside to outside.
Use with new lug bolts / nuts.
Also used as a light weight rim for antique pulling tractors.
Not designed for tubeless applications
Replacement Numbers
Z130
