Description
Quality Aftermarket Universal Oil Pressure Gauge (0 – 80 PSI)
For International Tractor Models:
I4, H, HV, Super H, Super HV, I9, ID9 (To Sn: 12425), M, MD To Sn: 8246, Super M, MDV (To Sn: 8246), MTA, Super MTA, MV, Super MV, Super MVTA, O4, O6, ODS6 (To Sn: 4926), OS4, OS6, T340, T5, T6, Super W4, W4, Super W6, Super W6TA, W6, W9, WD6 (To Sn: 4926), WD9 (To Sn: 12425), WDR9 (To Sn: 12425), WR9, WR9S, 240, 300, 330, 340, 350, 400, 450, 460, 560, 600, 650, 660
IH Combines: 91, 93, 195
IH Industrial: T6, 500, 3514, 3616, 3800, 3850, I4, I6, ID6 (up to SN 4926), T4, T6-61, T9
Windrower: 275, 375
All listed models using 80 Lb. gauge
Specifications
- Mounts with studs and a bracket in the dash in a 2″ diameter hole
- No logo
- Black face with white letters
- Chrome bezel
- 1/8″ NPT male thread
- May vary from original appearance
- Line adapter sold separately
Unless you can reuse your old adapter fitting for the oil line to the gauge, you will need one of the following depending on the line size:
1/8″ NPT to 1/8″ Compression: JJS1992
1/8″ NPT to 1/4″ Compression: JJS1993
1/8″ NPT female to 1/4″ Tubing female: JJS8531
