Description
PRV Audio 2″ Exit Phenolic Compression Driver 220 Watts Max D3220Ph
The PRV Audio D3220Ph, pro audio phenolic compression driver offers unsurpassed vocal and midrange reproduction. The specially designed phenolic diaphragm on a Kapton former offers a smooth sound required for proper voice production systems. The D3220Ph with a 2” opening and large 3” voice coil is perfect for large venue loudspeaker enclosures or line array systems where a high sound quality and SPL is required. 4 M6 bolt mounts permit mounting to most 2” waveguides. D3220Ph is designed to ensure a quality sound and long-lasting play in most any environment.
Features
• Throat Diameter: 2″
• Type: Bolt-On
• Nominal Impedance: 8Ω
• Rated AES Power Handling (RMS): 110 Watts
• Program Power: 220 Watts
• Nominal impedance: 8 Ohms
• Rated AES Power Handling (RMS): 110 Watts
• Program Power: 220Watts
• Sensitivity 2.83V at 1m: 109 dB
• Frequency Response at -10dB: 650 – 7,500 Hz
• Voice Coil Diameter: 3”(76.2 mm)
• Voice Coil Wire: Copper
• Voice Coil Former Material: Kapton
• Diaphragm Material: Phenolic resin
• Flux Density: 1.80 T
• Magnet Material: Ferrite
• Overall Diameter: 6.69” (170 mm)
• Overall Depth: 2.75” (70 mm)
• Mounting Bolt Circle: M6 x 4” (101.6 mm)
