Heavy-Duty 2-Piece Tie Rod Kit for Allis Chalmers Tractors – Replaces OEM Numbers 249418, 254661, and 254662

Description

Quality Aftermarket Tie Rod
Fits Allis Chalmers Tractor Models:
WD, WD45, 175 (up to SN 2035), 180, 185, 190, 190XT, 200
If cut to length: D14, D15, D17, D19, 170 (up to SN 7500)
Fits CA models when using a 7-degree tapered reamer to fit steering arms
Specifications

• The inside tie rod measures 16-3/8″ long from the grease fitting to the end
• 0.782″ diameter rod
• Outer tube is 17-3/8″ long from the grease fitting to the end
• The tie rod end tapers from 0.660″ to 0.735″
• Extended length with tie rod inserted 3 1/4 inches is 30 1/2 inches.(measurement from tie rod center to tie rod center)
• Collapsed it is 18 3/4 inches. (measurement from tie rod center to tie rod center)

Replacement Numbers
