Front wheel rim for Allis Chalmers tractors: 6-bolt pattern, 4.25×16 size, features four square weight holes for balanced mounting — compatible with part numbers 235086, 248460, and 70235086.

Description

Quality Aftermarket Front Rim – 6 Lug
Fits Allis Chalmers Tractor Models:
D15 (SN9001 and up), D17 (SN 75001 and up), D19, ED40, 160, 170, 175, 180, 185, 190, 190XT, 6060, 6070
It is recommended to measure BEFORE purchase. A different size may have been installed on your tractor at one time. Please contact us if you’d like further verification before you purchase.
JJAgParts is not responsible for return shipping on misordered rims.
Specifications

• 4.25″ x 16″ front wheel
• 6 lug
• 4.625″ pilot hole inside diameter
• 6″ center to center bolt pattern
• 4″ backspacing
• 2500 lb. capacity
• Fits 5.50″ x 16″ and 6.00″ x 16″ tires
• 4 square wheel weight holes

Not designed for tubeless applications.
To determine backspacing, lay the wheel flat on the ground with the back of the wheel facing up. Next lay a straightedge across the wheel and measure the distance from the backside of the mounting surface to the straightedge.
To determine the width of rim, measure on the inside from bead to bead, not outside to outside
Use with new lug bolts / nuts
Does not fit imported compact tractors
Replacement Numbers
235086
248460
70235086
70248460
