Front Wheel Rim – 6-Lug, 4.5″ x 16″ – Compatible with John Deere Tractors (Part #AN241675 / JD3002)

Description

Quality Aftermarket Front Rim
Fits John Deere Tractor Models:
1020, MT, 40, 430, 435, 820 (3 Cylinder), 830 (3 Cylinder), 1520, 1530, 2020, 2030, 2040, 2240, 2440, 2630, 2640, MI, 301A, 401, 4500, 301, 401B, 302, 400, 440, 300, 420
Serviceable for some, rim is 1/2″ wider.
It is recommended to measure BEFORE purchase. A different size may have been installed on your tractor at one time. Please contact us if you’d like further verification before you purchase.
JJAgParts is not responsible for return shipping on misordered rims.
Specifications

• 4.5″ x 16″
• 6 lug
• 4.625″ pilot hole inside diameter
• 6″ center to center bolt pattern
• 4.75″ Backspacing
• 2500 lb. capacity
• Fits tires:
  • 5.50″ x 16″
  • 6.00″ x 16″

Four(4) Round wheel weight holes. For square wheel weight holes, please see JJS15344.
To determine the width of rim, measure on the inside from bead to bead, not outside to outside.
Not designed for tubeless applications
Use with new lug bolts / nuts
Does not fit imported compact tractors
Replacement Numbers
AN241675
JD3002
