Essential carburetor repair kit designed for Marvel Schebler models on John Deere 4000-series tractors including 4010 and 4020

Description

Basic Carburetor Repair Kit (For Marvel Schebler aluminum carburetors)
Fits John Deere 4000, 4010, 4020 Tractors With Marvel Schebler USX20, USX30, USX35, USX48SL carburetors
Specifications Kit includes:diaphragmidle adjust needle (jam nut version)throttle shaftneedle and seatfloat lever pinchoke and throttle shaft sealsneedle valveidle adjustment screwgaskets and instructions
Includes parts shown in picture aboveFor reassembly purposes only, instruction sheet and diagram shows parts that are not included.
Fits listed Marvel Schebler aluminum carburetors. Make sure to find your carburetor manufacturer number in the list below. If your number is not listed, then this kit is not the correct kit for your application.
Carburetor Numbers
USX20, USX30, USX35, USX48SL
AR30280R, AR32636R, AR52450R, AR34244R, AR10110R, AR45160R – OEM Carb
Replacement Numbers
