DS18 Elite 3.5″ Full Range Speakers 4 Ohm ZXI-354
The ZXI series is the go to DS18 line for great sounding audio that not only has very high volume, but also amazing sound quality. The ZXI 354 is a 3.5″, 4 ohm full range speaker that is designed for mid-tier audio enthusiasts who want an amazing range of frequencies and loudness. The 1 way design will ensure that you receive a full range of frequencies for an audio experience that you will truly remember.
Features
• The ZXi line is a complete line of amps, subs, mids, and tweeters so you can match all your equipment up to be the same for an amazing show quality look.
• 3.5″ inch 1 way 4 ohm speaker requiring 40w RMS and 120w max power handling that gives amazing sound from low to extremely high volume.
• 1 -way design will be sure to give you a full range of frequencies for an amazing audio experience to remember.
• Nominal Diameter 3.5”
• Nominal Impedance 4 ohm
• RMS Power Handling 40W
• MAX Power Handling 120W
• Sensitivity (1w/1m) 89dB
• Frequency Response 120Hz-20KHz
• Recommended HI Pass Crossover 140Hz
• Voice Coil Diameter 1” / 25.5mm
• Voice Coil Former Material KSV
• Winding Material EISV
• Cone Material Glass fiber
• Surround Material Rubber
• Basket Material Steel
• Magnet Material. Barium Ferrite
• Magnet Weight 10.9 oz / 310g
• Thiele & Small Parameters
• Equivalent Volume 0.55L
• Excursion (one way) 1.4mm
• Free Air Resonance 140Hz
• Mechanical Factor 7.08
• Electrical Factor 1.37
• Total Factor 1.15
• Mechanical Mass 3.2g
• Mechanical Compliance 402mm/N
• BL Factor 2.938
• Cone Area 32cm2
• DC Resistance 4.2 ohm
• Mechanical Mass w/o air 3.0g
• Overall Diameter 3.50” / 89mm
• Overall Depth 1.65” / 42mm
• Front Mount Baffle Cutout 2.80” / 71mm
• Mouting Depth 1.49” / 37.8mm
• Motor Diameter 2.36” / 60mm
