Delco 1948113 Starter Drive Housing – Compatible with Allis Chalmers Tractors

Description

Quality Aftermarket Starter Drive Housing
Fits Allis Chalmers Tractor Models:
D14 (SN 19001 and up), D15, H3
Gas and LP with factory 12 Volt starter number 1107758 or 1109388 for all listed models
Specifications

• Dimensions from end of nose cone where it bolts to starter is 3.775″ to first edge of starter drive gear opening
• 2.575″ to center of mounting bolt locating hole
• 6.420″ overall housing length
• 1/4″ – 20 inside diameter threaded holes
• Includes bushing

Installation Tips
Before installing this replacement housing, make sure the below conditions are first checked and satisfied (warranty void if broken.)

• The (main) reasons a starter nose will break:
  • Bent armature shaft
  • Ignition timing is incorrect
  • Improper drive to ring gear clearance
  • Defective distributor cap / wires causing the engine to kick back

Delco Numbers
1948113
Replacement Numbers
233294
70233294
